Diodes Incorporated ¼¯³Éµç·£¨IC£© AP7333-25SAG-7

¡¡¡¡Diodes Incorporated ¼¯³Éµç·£¨IC£© AP7333-25SAG-7

¡¡¡¡The AP7333 is a 300mA£¬ fixed output voltage£¬ low dropout linear regulator. The device included pass element£¬ error amplifier£¬ band-gap£¬ current limit and thermal shutdown circuitry. The characteristics of low dropout voltage and low quiescent current make it suitable for low power applications£¬ for example£¬ battery powered devices. The typical quiescent current is approximately 65¦ÌA. Built-in current-limit and thermal-shutdown functions prevent IC from damage in fault conditions. The AP7333 is available in SOT23 packages with different pin-outs. 300mA Low Dropout Regulator in 3-pin package ? Very low IQ over full load£º 65?A ? Wide input voltage range£º 2V to 6V ? Fixed output options£º 1.0V to 3.3V ? PSRR£º 65dB typical at 100Hz ? Fast start-up time£º 80?s ? Stable with low ESR£¬ 1?F ceramic output capacitor ? Excellent Load/Line Transient Response ? Low dropout£º 300mV typical at 300mA ? Current limit protection ? Short circuit protection ? Thermal shutdown protection ? Ambient temperature range£º -40?C to 85¡ãC ? SOT23 and SOT23R£º Available in ¡°Green¡± Molding Compound £¨No Br£¬ Sb£© ? Lead Free Finish/RoHS Compliant £¨Note 1£©
