4¦¸ÂÞ¶÷4/8ͨµÀiCMOS¶à·¸´ÓÃÆ÷ADG1408-EP/ADG1409-EPÊý¾Ý±í

¡¡¡¡The ADG1408-EP/ADG1409-EP are monolithic iCMOS? analog multiplexers comprising eight single channels and four differential channels£¬ respectively. The ADG1408-EP switches one of eight inputs to a common output£¬ as determined by the 3-bit binary address lines£¬ A0£¬ A1£¬ and A2. The ADG1409-EP switches one of four differential inputs to a common differential output£¬ as determined by the 2-bit binary address lines£¬ A0 and A1. An EN input on both devices is used to enable or disable the device. When disabled£¬ all channels are switched off. The iCMOS £¨industrial CMOS£© modular manufacturing process combines high voltage CMOS £¨complementary metal-oxide semiconductor£© and bipolar technologies. It enables the development of a wide range of high performance analog ICs capable of 33 V operation in a footprint that no other generation of high voltage parts has been able to achieve. Unlike analog ICs using conventional CMOS processes£¬ iCMOS components can tolerate high supply voltages while providing increased performance£¬ dramatically lower power consumption£¬ and reduced package size. The ultralow on resistance and on resistance flatness of these switches make them ideal solutions for data acquisition and gain switching applications where low distortion is critical. iCMOS construction ensures ultralow power dissipation£¬ making the parts ideally suited for portable and batterypowered instruments. Full details about this enhanced product are available in the ADG1408/ADG1409 data sheet£¬ which should be consulted in conjunction with this data sheet.
