¸ßµçÔ´µçѹ200mhzÔöÒæÎȶ¨µÄÔËËã·Å´óÆ÷ISL55004

¡¡¡¡The ISL55004 is a high speed£¬ low power£¬ low cost monolithic operational amplifier. The ISL55004 is unity-gain stable and features a 300V/?s slew rate and 200MHz bandwidth while requiring only 8.5mA of supply current per amplifier. The power supply operating range of the ISL55004 is from ¡À15V down to ¡À2.5V. For single-supply operation£¬ the ISL55004 operates from 30V down to 5V. The ISL55004 also features an extremely wide output voltage swing of -12.75V/+13.4V with VS = ¡À15V and RL = 1k?¡£ At a gain of +1£¬ the ISL55004 has a -3dB bandwidth of 200MHz with a phase margin of 55¡ã¡£ Because of its conventional voltage-feedback topology£¬ the ISL55004 allow the use of reactive or non-linear elements in its feedback network. This versatility combined with low cost and 140mA of output-current drive makes the ISL55004 an ideal choice for price-sensitive applications requiring low power and high speed. The ISL55004 is in a 14 Ld SO £¨0.150¡±£© package and specified for operation over the full -40¡ãC to +85¡ãC temperature range
